Application
- Swimming pools of all types and size (including in-floor cleaning systems, solar heating systems, water features or water garden)
- In-ground spas or in-ground pool/spa combinations
Specifications:
- Suction lift: Up to 7.3’ above water level
- Nominal Motor Horsepower (hp): 1.50
- Total Horsepower (thp): 1.50
- Service Factor: 1.0
- Hydraulic Horsepower (hhp): 0.721
- Speed (rpm): 750-3450
- WEF: 8.30
- Volts: 230
- Amps: 3,450 RPM's = 5.94 amps, 2,500 RPM's = 2.4 amps, 1,725 RPM's = .95 amps and 750 RPM's = .34 amps
Pump Features
- Self-priming (vertical suction lift up to 7.3’ above water level)
- Quiet Operation
- Up to 80% energy savings over single speed pumps
- Full Variable Speed (750-3450 RPMs)
- Strainer basket cover removes easily for cleaning
- Transparent strainer basket cover lets know when basket needs cleaning
- All components molded of corrosion-proof reinforced thermoplastic for extra durability and long life
- Drain plug for easy pump winterization
- Mechanical seals are made from carborundum & graphite for long life and low noise
- Motor shaft is stainless steel grade 304
- Energy-Star Certified!
Controller Features
- Simple user interface
- Onboard time of day schedule
- Adjustable priming mode
- Programmable quick clean mode
- Diagnostic alarm display and retention
- One week. clock retention for power outages
- WARRANTY 1-YEAR
Pump Performance Curve
Pump Dimensions
Product Specifications
HP:
1.5 HP
Manufacturer:
DG Pool Supply
Pool / Spa Type:
Inground
Volts:
230 V
Speed:
Variable
Amps:
5.94 amp
Service Factor:
1.0
Total HP:
1.5 HP
Port Size:
1.5 in.
Pump Model:
Rapids
Installation:
Residential
Installation & safety: Installation must comply with the National Electrical Code (NEC) Article 680 and all local codes, and must be performed by a qualified pool professional or licensed electrician. Disconnect power before servicing.
California Proposition 65 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Warranty: Covered by the manufacturer warranty (terms in the product documentation).
